G2130 Bow Shackle
Drop Forged Anchor Shackles Bolt type Anchor Shackle G2130 S2130
Bolt type Anchor Shackles meets the performance requirements of federal specification RR-C-271D. Type IVA, Grade A, Class 3, except for those provisions required of the contractor.
Capacities 1/3 thru 200 metric tons.
Forged-quenched and tempered, with alloy pin.
Working load limit permanently shown on every shackle.
Hot Dip galvanized or self-colored.
|
Nominal size (in.) |
Working Load Limit (T) |
Weight (kg) |
Dimensions (mm) |
Tolerance +/- |
||||||||||
|
A |
B |
C |
D |
E |
F |
H |
L |
N |
G |
A |
||||
|
3/16 |
1/3 |
0.03 |
9.65 |
6.35 |
22.4 |
4.85 |
15.2 |
14.2 |
37.3 |
24.9 |
4.85 |
1.50 |
1.50 |
|
|
1/4 |
1/2 |
0.05 |
11.9 |
7.85 |
28.7 |
6.35 |
19.8 |
15.5 |
46.7 |
32.5 |
6.35 |
1.50 |
1.50 |
|
|
5/16 |
3/4 |
0.10 |
13.5 |
9.65 |
31.0 |
7.85 |
21.3 |
19.1 |
53.0 |
37.3 |
7.85 |
3.30 |
1.50 |
|
|
3/8 |
1 |
0.15 |
16.8 |
11.2 |
36.6 |
9.65 |
26.2 |
23.1 |
63.0 |
45.2 |
9.65 |
3.30 |
1.50 |
|
|
7/16 |
1.1/2 |
0.22 |
19.1 |
12.7 |
42.9 |
11.2 |
29.5 |
26.9 |
74.0 |
51.5 |
11.2 |
3.30 |
1.50 |
|
|
1/2 |
2 |
0.36 |
20.6 |
16.0 |
47.8 |
12.7 |
33.3 |
30.2 |
83.5 |
58.5 |
12.7 |
3.30 |
1.50 |
|
|
5/8 |
3.1/4 |
0.76 |
26.9 |
19.1 |
60.5 |
16.0 |
42.9 |
38.1 |
106 |
74.5 |
17.5 |
6.35 |
1.50 |
|
|
3/4 |
4.3/4 |
1.23 |
31.8 |
22.4 |
71.5 |
19.1 |
51.0 |
46.0 |
126 |
89.0 |
20.6 |
6.35 |
1.50 |
|
|
7/8 |
6.1/2 |
1.79 |
36.6 |
25.4 |
84.0 |
22.4 |
58.0 |
53.0 |
148 |
102 |
24.6 |
6.35 |
1.50 |
|
|
1 |
8.1/2 |
2.57 |
42.9 |
28.7 |
95.5 |
25.4 |
68.5 |
60.5 |
167 |
119 |
26.9 |
6.35 |
1.50 |
|
|
1.1/8 |
9.1/2 |
3.75 |
46.0 |
31.8 |
108 |
28.7 |
74.0 |
68.5 |
190 |
131 |
31.8 |
6.35 |
1.50 |
|
|
1.1/4 |
12 |
5.31 |
51.5 |
35.1 |
119 |
31.8 |
82.5 |
76.0 |
210 |
146 |
35.1 |
6.35 |
1.50 |
|
|
1.3/8 |
13.1/2 |
7.18 |
57.0 |
38.1 |
133 |
35.1 |
92.0 |
84.0 |
233 |
162 |
38.1 |
6.35 |
3.30 |
|
|
1.1/2 |
17 |
9.43 |
60.5 |
41.4 |
146 |
38.1 |
98.5 |
92.0 |
254 |
175 |
41.1 |
6.35 |
3.30 |
|
|
1.3/4 |
25 |
15.4 |
73.0 |
51.0 |
178 |
44.5 |
127 |
106 |
313 |
225 |
57.0 |
6.35 |
3.30 |
|
|
2 |
35 |
23.7 |
82.5 |
57.0 |
197 |
51.0 |
146 |
122 |
348 |
253 |
61.0 |
6.35 |
3.30 |
|
|
2.1/2 |
55 |
44.6 |
105 |
70.0 |
267 |
66.5 |
184 |
145 |
453 |
327 |
79.5 |
6.35 |
6.35 |
|
|
3 |
85 |
70 |
127 |
82.5 |
330 |
76.0 |
200 |
165 |
546 |
365 |
92.0 |
6.35 |
6.35 |
|
|
3.1/2 |
120 |
120 |
133 |
95.5 |
372 |
92.0 |
229 |
203 |
626 |
419 |
105 |
6.35 |
6.35 |
|
|
4 |
150 |
153 |
140 |
108 |
368 |
104 |
254 |
229 |
653 |
468 |
116 |
6.35 |
6.35 |
|
Note:
Maximum proof load is 2.0 times the working load limit, minimum ultimate strength is 6 times the working load limit. For working load limit reduction due to side loading applications.
